The YPS Nova BSW is an outdoor rated 3-in-1 Moving Head. It is a high-powered lighting fixture designed not just for beam use, but also for spot and wash effects. Making it an essential tool for concerts, theaters, outdoor events such as haunts and drive-thrus, and professional stage productions. With its IP65 waterproof rating, this fixture is built to withstand rain, snow, and outdoor conditions while delivering stunning lighting effects. These aren’t just beams—they’re brilliance in action!

Key Features

Powerful and Versatile Lighting

• 720W LED for intense brightness and clarity
• 3-in-1 functionality with beam, spot, and wash effects
• Wide zooms range from 4 to 40 degrees for precise beam control
• IP65 waterproof rating for both indoor and outdoor applications
• Energy-saving mode that reduces power consumption when idle

Control and Operation

• DMX512 and RDM compatibility for remote control and device management
• 20 DMX channels for precise control over movement, color, dimming, effects, and strobe
• LCD touchscreen display with both touch and encoder controls
• Multiple control modes including DMX, automatic programs, sound activation, and master-slave synchronization

Built for Performance and Durability

• Rugged aluminum housing that is lightweight yet durable
• Automatic return correction ensures positioning accuracy
• Smart cooling system with copper tube and fan cooling for efficient heat dissipation
• Temperature monitoring technology to protect components from overheating
• Heavy-duty rigging system for safe and stable mounting with adjustable brackets and safety clamps

Technical Specifications

Input Voltage – AC 100V–240V, 50/60Hz

Rated Power – 720W

Light Source – 600W LED

Color Temperature – 9000K

Average LED Lifespan – 20,000 hours

CRI – ≥80

Zoom Range – 4°–40°

Gobo System – 5 fixed gobos + open white + flame effect wheel; 7 rotating glass gobos + open white

Color System – 6-color wheel + open white, CMY color mixing, and CTO adjustment from 3300K–5500K

Prism System – 8-facet rotating prism + 6-facet linear prism

Control Protocol – DMX512 and RDM

Control Modes – DMX, RDM, Autorun, and Sound-Activated

DMX Channels – 24CH

Display – OLED display with waterproof smart touch keys

Power Input/Output – Power input and output connections

Signal Input/Output – 3-pin or 5-pin DMX

Software Updates – Firmware upgrades through the DMX interface

Waterproof Rating – IP65

Housing Material – Magnesium-aluminum alloy

Net Weight – 22 kg (48.5 lbs.)
