The YPS Nova BSW is an outdoor rated 650W 3-in-1 Moving Head. It is a high-powered lighting fixture designed not just for beam use, but also for spot and wash effects. Making it an essential tool for concerts, theaters, outdoor events such as haunts and drive-thrus, and professional stage productions. With its IP65 waterproof rating, this fixture is built to withstand rain, snow, and outdoor conditions while delivering stunning lighting effects. These aren’t just beams—they’re brilliance in action!

Key Features

Powerful and Versatile Lighting

• 650W for intense brightness and clarity
• 3-in-1 functionality with beam, spot, and wash effects
• Wide zoom range from 4 to 50 degrees for precise beam control
• IP65 waterproof rating for both indoor and outdoor applications
• Energy-saving mode that reduces power consumption when idle

Control and Operation

• DMX512 and RDM compatibility for remote control and device management
• 20 DMX channels for precise control over movement, color, dimming, effects, and strobe
• LCD touchscreen display with both touch and encoder controls
• Multiple control modes including DMX, automatic programs, sound activation, and master-slave synchronization

Built for Performance and Durability

• Rugged aluminum housing that is lightweight yet durable
• Fast and accurate movement with 540-degree pan and 270-degree tilt, featuring 16-bit precision
• Automatic return correction ensures positioning accuracy
• Smart cooling system with copper tube and fan cooling for efficient heat dissipation
• Temperature monitoring technology to protect components from overheating
• Heavy-duty rigging system for safe and stable mounting with adjustable brackets and safety clamps

Technical Specifications

Input Voltage – AC 110V-240V, 50/60Hz

Light Source – MSD Platinum 21

Zoom Range – 4° – 50°

Light Source – High-performance discharge lamp

Dimming Range – 0% – 100% electronic dimming

Strobe Speed – 1 – 25Hz

Gobo System – 12 fixed gobos and 7 rotating gobos

Color System – 12-color wheel with rainbow and mixing

Prism System – 3-facet and 8-facet rotating prisms

Control Protocol – DMX512 and RDM

Waterproof Rating – IP65

Movement Range – Pan: 540° (1.77 turns), Tilt: 270° (0.75 turns)

Fixture Dimensions – 29 × 12 × 17 inches

Net Weight – 64 pounds
